Features
|
Full Netcom 4G, support WiFi, BT, GPS
|
|
Exquisite workmanship,and elegant outlooking
|
|
Embedded high extensibility Android system
|
|
Front(5MP) and Rear(8MP), focus automatically
|
|
32-diameter speaker with double chambers
|
|
2.4 inch touch screen, easy to oprate.
|
|
Simple and convenient function buttons.
|
|
Multi system languages
|
|
Support group call, single call
|
|
Priority calling, Monitor, Recording
|
|
Level-to-level administration and dispatch
|
|
Support GPS Location and track
|
|
Multi platform support, MYT, RealPTT, Zello, etc.
|
Product Description
|
item
|
value
|
|
Private Mold
|
YES
|
|
Place of Origin
|
China
|
|
|
Fujian
|
|
Brand Name
|
Mytetra
|
|
Model Number
|
MYT-V970S
|
|
Type
|
Handheld
|
|
Dimensions
|
180*65*24(mm)
|
|
Frequency Range
|
LTE/WCDMA/GSM
|
|
Storage Channel
|
Infinite
|
|
Talk Range
|
Worldwide
|
|
Platform
|
MTK MT6737WM
|
|
Operate system
|
Android 9.0
|
|
Camera
|
Front(5MP) and Rear(8MP), focus automatically
|
|
Memory
|
1GB(RAM)+ 8GB(ROM)
|
|
Battery capacity
|
3500mAh
|
|
Weight
|
262g
|
|
Screen size
|
3 inch 360*640 Multi-touch Screen
|
|
Output Power
|
1.3W
|
|
Radio Type
|
Network Radio
|
|
Product Name
|
Walkie Talkie PTT Phone
|
Specification
|
General Specifications
|
|
|
Network support
|
LTE/WCDMA/GSM
|
|
Platform
|
MTK MT6737WM
|
|
Operate system
|
Android 9.0
|
|
Camera
|
Front(5MP) and Rear(8MP), focus automatically
|
|
Memory
|
8GB(ROM)+1GB(RAM)
|
|
Extended Memory
|
Up to 32GB
|
|
Speaker+handset
|
Support
|
|
Speaker & earhpone connector
|
M6
|
|
GPS
|
Support
|
|
battery capacity
|
3500mAh
|
|
Dimensions: H x W x D (mm)
|
180*65*24(mm)
|
|
Weight
|
262g
|
|
Screen size
|
3 inch 360*640 Multi-touch Screen
|
|
Standby Time
|
29hours
|
|
Electrical Specifications
|
|
|
|
FDD(B1/3/5/7/8/20/28A/28B) TDD(B38/B40/B41(20M)
|
|
WCDMA(B1/5/8)
|
|
|
GSM(B2/3/5/8)
|
|
|
|
FDD(B2/3/4/5/7/8/12/13/17/28a&b/66) TDD(B38/40/41)
|
|
WCDMA(B2/4/5)
|
|
|
GSM(B2/3/5/8)
|
|
|
Working Current
|
Power Off: ≤20uA; Sleep mode: ≤3mA;
|
|
Working Temperature/Humidity
|
T: -30℃~+75℃; H: 5%~95%
|
|
Storage Temperature
|
-40℃~+90℃
|
|
Rated Audio Output Power
|
1.3W
|
|
Audio Distortion@ Rated Audio
|
10%
|
|
Charger
|
5V 1A Micro USB
|
|
Max Output Power
|
24dBm~33dBm, ±2dBm
|
|
RX sensitivity
|
≤-110dBm
|
