Welcome to Rugby Radios UK
Audio equipment, Two way Radio Communications, and Storage needs for businesses, Sporting & Events and consumers
Now back in stock - with gps
Number of Channels: 128
Model: DM-1801
Unit Quantity: 1
Band: UHF,VHF
Band Type: Dual Band
MPN: DM-1801
Unit Type: Unit
Brand: Baofeng
Frequency Range: 136-174MHz UHF:400-480MHz
New Baofeng 2022 edition DM-1801 Tier 1+2 Dual Time Slot
UV Dual band 136-174 & 400-
470MHz DMR Digital Radio
Note: if you need software, please contact us.
Main features
*Dual time slot: Perfectly compatible with m o t o r o l a
*Dual Band dual display dual standby
*DMR digital
*SMS function
*AMBE+2TM Vocodec
*Emergency mode
Specification
Frequency Range: VHF 136-174MHz &UHF 400-470MHz
Storage channel: 1024
Operating Voltage: DC 7.4V
Frequency Stability:±1.0ppm
Operating Temperature:-30°c ~ 60°c
Antenna Impedance:50Ω
Battery Capacity:2200mAh/16.28wh
Weight: about 274g(with battery & antenna)
Volume: 136*62*36mm(antenna 14cm not including)
Transmitting
Output Power: 1W/5W
Digital: Tier 1 and Tier 2
Adjacent channel:≤-65dB ≤-60dB
Modulation Distortion:≤5%
Digital Protocol: ETSI-TS102 361-1,-2,-3
Vocoder type: AMBE+2TM
Receiving
Analog sensitivity:-122dBm (12dB SINAD)
Digital sensitivity:-120dBm (BER ≤5%)
Audio Power:1W
Audio Distortion:<10%
Inter-mediation:≥62dB / ≥ 58dB
Adjacent channel selectivity:≥65dB /≥60dB
Receiving current:≤380mA
PM Noise :≥ 45dB*25KHz; ≥ 40dB*12.5KHz
