Features
|
Full Netcom 4G, support WiFi, BT, GPS
|
|
Exquisite workmanship,and elegant outlooking
|
|
Embedded high extensibility Android system
|
|
Front(2MP) and rear(5MP), focus automatically
|
|
32-diameter speaker with double chambers
|
|
2.4 inch touch screen, easy to oprate.
|
|
Numeric keyboard, support phone call
|
|
Multi system languages
|
|
Support group call, single call
|
|
Priority calling, Monitor, Recording
|
|
Level-to-level administration and dispatch
|
|
Support GPS Location and track
|
|
Multi platform support, MYT, RealPTT, Zello, etc.
|
|
NFC optional
|
Product Description
|
item
|
value
|
|
Private Mold
|
Yes
|
|
Place of Origin
|
China
|
|
|
Fujian
|
|
Brand Name
|
MYT
|
|
Model Number
|
MYT-V968S
|
|
Type
|
Handheld
|
|
Dimensions
|
180*65*24(mm)
|
|
Frequency Range
|
2G/3G/4G/Wifi
|
|
Storage Channel
|
NONE
|
|
Talk Range
|
unlimited
|
|
Walkie Talkie Type
|
4G POC
|
|
Water Resistance Level
|
IPX4
|
|
Product Name
|
POC Radio
|
|
Certification
|
CE FCC Certificate
|
|
Warranty
|
12 Months
|
|
Color
|
Balck
|
|
Output Power
|
1.3W
|
|
Operating System
|
Android 7.0
|
|
Weight
|
262g
|
|
Battery capacity
|
3500mAh
|
|
Material
|
PVC+ABS
|
|
Working Temperature
|
T: -30℃~+75℃; H: 5%~95%
|
Specification
|
General Specifications
|
|
|
Network support
|
LTE/WCDMA/GSM
|
|
Platform
|
MTK MT6737WM
|
|
Operate system
|
Android 7.0
|
|
Camera
|
Front(2MP) and rear(8MP), focus automatically
|
|
Memory
|
8GB(ROM)+1GB(RAM)
|
|
Extended Memory
|
Up to 32GB
|
|
Speaker+handset
|
Support
|
|
Speaker & earhpone connector
|
M6
|
|
GPS
|
Support
|
|
battery capacity
|
3500mAh
|
|
Dimensions: H x W x D (mm)
|
180*65*24(mm)
|
|
Weight
|
262g
|
|
Screen size
|
2.4 inch 240(RGB) * 320 Dots Multi-touch Screen
|
|
Standby Time
|
29hours
|
|
Electrical Specifications
|
|
|
|
FDD-LTE: B1/B3/B7
|
|
WCDMA: B1/B2/B5/B8
|
|
|
GSM: B2/B3/B5/B8
|
|
|
Working Frequency(EU)
|
FDD-LTE:B1/B3/B7/B20/B28
TDD-LTE:B38/39/40/41 |
|
WCDMA: B1/B2/B5/B8
|
|
|
GSM: B2/B3/B5/B8
|
|
|
|
FDD-LTE: B2/B4/B5/B7/B12/B13/B17/B28A/B28B
TDD-LTE: B38 |
|
WCDMA: B1/B2/B5/B8
|
|
|
GSM: B2/B3/B5/B8
|
|
|
Working Current
|
Power Off: ≤20uA; Sleep mode: ≤3mA;
|
|
Working Temperature/Humidity
|
T: -30℃~+75℃; H: 5%~95%
|
|
Storage Temperature
|
-40℃~+90℃
|
|
Rated Audio Output Power
|
1.3W
|
|
Audio Distortion@ Rated Audio
|
10%
|
|
Charger
|
5V 1A Micro USB
|
|
Max Output Power
|
24dBm~33dBm, ±2dBm
|
|
RX sensitivity
|
≤-110dBm
|
